Fusion unit with documentation function
Powerful universal fusion unit FRIAMAT 6 110V
- Bluetooth
- Full documentation
- Full traceability functions
- 20,000 fusion protocols
- Output via USB interface or app (smart phone)
- Supervisor function
- State-of-the-art toroidal core technology with active cooling
- Bright colour TFT display
- With mini scanner
UK metric (availability from mid 2025):
- Extra long fusion cable (4 m)
- Extra long power cable (5 m)
- Weight approx. 19.0 kg
US imperial:
- Extra long fusion cable (13 ft)
- Extra long power cable (16 ft)
- Weight approx. 42 lbs
Note:
Possibility of updating the FRIAMAT software via the USB interface by the user.
Other mains plugs variants on request.
1D/2D scanner on request.
| Reference | Short text | BX | Weight [kg] |
|---|---|---|---|
| 611129-UK0 | With UK mains plug | 1 | 18,950 |
| 611129-UKC | With CAN mains plug | 1 | 18,950 |
| 611129-USI | With US mains plug and special transport case | 1 | 18,950 |
Technical data 1) |
FRIAMAT 6 110V US 2) |
FRIAMAT 6 110V UK 2) |
Type of device |
Universal electrofusion unit with traceability and documentation function and Bluetooth interface |
Universal electrofusion unit with traceability and documentation function and Bluetooth interface |
Model with mini scanner |
Order no. 611129 |
Order no. 611129 |
Model with reader wand |
no |
no |
Model with 1D/2D scanner |
Order no. 614129 |
Order no. 614129 |
Maximum diameter |
Up to d 42" IPS 3) |
Up to d 1200 3) |
Input voltage section |
AC 95 V - 138 V |
AC 95 V - 138 V |
Frequency range |
44 Hz … 66 Hz |
44 Hz … 66 Hz |
Current consumption |
AC 30 A maximum |
AC 30 A maximum |
Power |
3.5 kW |
3.5 kW |
Unit fuse |
16 A sluggish |
16 A sluggish |
Welding tension |
8 – 48 V |
8 – 48 V |
Output current |
maximum 110 A |
maximum 110 A |
Welding current monitoring |
Short circuit and interruption |
Short circuit and interruption |
Barcode type |
1D-Code 2/5 interleaved, Code 128; 2D-Code (QR; Aztec; Data Matrix) according to ISO 12176-5 |
1D-Code 2/5 interleaved, Code 128; 2D-Code (QR; Aztec; Data Matrix) according to ISO 12176-5 |
Interface |
USB / Bluetooth® Low Energy V4.2 (CE, FCC, IC certified) |
USB / Bluetooth® Low Energy V4.2 (CE, FCC, IC certified) |
Documentation of fusion data |
Yes |
Yes |
Documentation of traceability data |
Yes |
Yes |
Data memory |
20.000 protocols |
20.000 protocols |
Log format |
PDF / CSV |
PDF / CSV |
Manual emergency barcode input |
Yes |
Yes |
FRIAMAT preCHECK function |
Yes |
Yes |
Software update via USB interface |
Yes |
Yes |
Fusion-Pass |
Optional (Order no. 623100) |
Optional (Order no. 623100) |
Supervisor-Pass |
Yes |
Yes |
Start/stop pass for remote control |
Optional (Order no. 624003) |
Optional (Order no. 624003) |
Working temperature range |
-4°F ... +122°F |
-20 °C ... +50 °C |
Language variants |
23 |
23 |
Connection cable |
16,4 ft with contour plug |
5 m with contour plug |
Fusion cable |
13,1 ft with connection plug Ø 4 mm |
4 m with connection plug Ø 4 mm |
Weight |
approx. 44 lbs |
approx.19 kg |
Dimensions W x D x H |
10,2 x 19,7 x 13,4 in |
260 x 500 x 340 mm |
Casing |
Protection category IP 54 / protection category I |
Protection category IP 54 / protection category I |
Approval / quality |
CE, ISO 9001, WEEE-Reg. no. DE 49130851, RoHS, REACH |
CE, ISO 9001, WEEE-Reg. no. DE 49130851, RoHS, REACH |
Accessories |
Operating instructions, transport box |
Operating instructions, transport box |
1) Subject to technical modifications. |
||
2) From year of construction Q4/2023 |
||
3) With the FRIAMAT prime eco, FRIALEN and FRIAFIT safety fittings up to 36" IPS |
||
can be fused in the entire working temperature range of -4°F +144 °F. |
||
Utilising processing fittings from other manufacturers is possible even up to 42" IPS |
||
and possibly larger. However, the specific power requirement of the fitting at the prevailing processing temperature must always be clarified beforehand with the fitting manufacturer. |
- High performance due to innovative toroidal transformer technology with flow-optimized, active cooling.
- High-resolution, extremely bright 4.3 “TFT color display. Documentation of fusion and traceability data. Memory space for up to 20,000 fusion logs. CSV or PDF file output to standard USB stick.
- With mini-scanner or 1D/2D scanner for reading 2D barcodes according to ISO 12176-5, Adapter bag, language selection, adjustable buzzer volume, manual emergency entry. Continuous monitoring of the entire fusion process and all device functions.
- With FRIAMAT preCHECK function: The most advanced way to fuse with foresight. The FRIAMAT automatically determines whether the next fusion can be performed completely to the end.
- The user himself can install software updates via USB interface.
- Integrated Bluetooth function for communication with the FRIAMAT App. At present, the use of the Bluetooth function is only permitted in the following countries: see operating instructions.
